MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ
MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ

MGR 0.25W 0.5W 1W 2W 100KΩ~39MΩ

Product ID : MGR 100KΩ~39MΩ 0.25W 0.5W 1W 2W
Product Tags :
Product Attributes :

Wire wound resistor is made by winding resistance wire. The resistor is made by winding high resistance alloy wire on the insulation frame. The outside is coated with heat resistant glaze insulating layer or insulating paint. Wire-wound resistance has low temperature coefficient, high precision resistance value, good stability, heat resistance and corrosion resistance%2

Product Description
  • Wire wound resistor is made by winding resistance wire. The resistor is made by winding high resistance alloy wire on the insulation frame. The outside is coated with heat resistant glaze insulating layer or insulating paint. Wire-wound resistance has low temperature coefficient, high precision resistance value, good stability, heat resistance and corrosion resistance, mainly used for precision high-power resistance, the disadvantage is that the high frequency performance is poor, the time constant is large.
  • Carbon composition resistor is made by pressing carbon and synthetic plastic.
  • Carbon film resistors are made by plating a layer of carbon on a porcelain tube and depositing the crystalline carbon on a ceramic rod skeleton, Carbon film resistor is the most widely used resistor with low cost, stable performance, wide range of resistance value, low temperature coefficient and voltage coefficient.
  • Metal film resistor is made by plating a layer of metal on the porcelain tube, and the alloy material is steamed and plated on the surface of the ceramic rod skeleton by vacuum evaporation,Compared with carbon film resistor, metal film resistor has higher precision, better stability, less noise and temperature coefficient. It is widely used in instrument and communication equipment.
  • Metal oxide resistor is made by plating a tin oxide layer on a porcelain tube and depositing a layer of metal oxide on an insulating rod. Because it is oxide itself, it is stable at high temperature, resistant to shock, strong load capacity according to the purpose, there are general, precision, high frequency, high pressure, high resistance, high power and resistance network
